Heatless adsorption dryer
JH-2000
Quantity
The working principle of the adsorption dryer
Adsorption dryers achieve the drying effect by"pressure change"(pressure swing adsorptionprinciple). Because the ability of the air to hold water vapor is inversely proportional to the pressure, a part of the dried air (called regeneration gas) is decompressed and expanded to atmospheric pressure, and this pressure change makes the expanding air drier, and then allows it to flow through the desiccant layer to be regenerated (that is, the drying tower that has absorbed enough water vapor) without air flow, and the dry regeneration gas sucks out the water in the desiccant and takes it out of the dryerto achieve the purpose of dehumidification. The two towers work in a circular cycle, without heat source, and continuously provide dry compressed air to the user's air system.
The form of an adsorption dryer
According to the regeneration method of adsorbent, it can be mainly divided into two types: heatless regeneration micro-heat regeneration dryer and thermal regeneration micro-heat regenerationdryer. Because the heatless micro-heat regeneration dryer works according to isothermal adsorption, it is also known as"pressure swingadsorption"and the thermal micro-heat regeneration dryer is the work of isobaric adsorption, also known as"variable temperature adsorption". In actual use, there is also a kind called micro-heat dryer, from the form, the micro-thermal regenerative dryer is also to heat the regenerated gas, but because the regenerated gas it uses is dry air with very low water content itself, it also belongs to the"pressure swing adsorption"dryer
Performance advantages of desiccant dryers
1. Well-designed adsorption tower
A large suction bed with a contact time of 6.25 seconds ensures that the saturated air entering the dryer is dried to the desired dew point and compensates for the natural aging of the adsorbent layer;
Large stainless steel airflow diffuser with reliable structure ensures that the airflow evenly passes through the adsorbent layer and eliminates thetrench flowphenomenon;
Suitable column size and convection mode of upstream drying and downstream regeneration are conducive to reducing the amount of regeneration gas and avoiding the fluidization of adsorbent and the contamination of the adsorbent layer;
Slow and complete pressurization program and time-delay switching design eliminates downstream airflow pulsation and prevents adsorbent movement and adsorbent abrasion;
Independent filling port and discharge port for easy replacement of adsorbent;
The tower body is manufactured in line with the national standard specifications for pressure vessels.
2. High-performance activated aluminaadsorbent
High compressive strength, abrasionresistance,high temperature resistance, non-hydrolysis;
Large specific surface area andstatic adsorptioncapacity.
3. A muffler with good effect
Symmetrical setting to reduce the noise superposition effect;
Special pressure reduction box, the muffler is easy to assemble and disassemble, and the sound reduction effect is good.
4. Imported pneumatic controller with two characteristics of high power and durability
The use of two-position five-way pilot valveand deep drying, filtration control gas to ensure precise control;
Double piston structure, high aerodynamic power, reliable action and fast response;
The controller is isolated from the main airflow and protected from moisture pollution.
5. Durable and reliable imported pneumatic butterfly valve intakevalveand regeneration/repressurization valve
Elastomerseat, thinnickel-plateddisc to ensure leak-free operation and provide low pressure drop;
The stem bushings ensure smooth operation without the need for on-site lubrication. 6. Regenerative gas regulating valve that can accurately adjust the flow
Uniquebalanced valveport design ensures precise adjustment;
The air flow always passes through the valve in the same direction, ensuring a stable and consistent flow;
The control valve and the orifice plateare set separately for easy control of the regeneration gas flow.
7. Reliable check valve
The use of a flexible valve seatensures proper closure, reduced wear, high temperature resistance and long service life.
8. Good safety and easy maintenance
Comply with pressure vessel standards;
The whole equipmentis not easy to corrode after sandblasting and anti-rust treatment;
Thenylon hose is under pressure of 1.5MPa (40°C);
The meter connection can be used as a valve, and it is easy to replace the pressure gauge;
Movable pipe connection, easy maintenance.
