Freeze dryer
JY-120A(W)
Quantity
Difference between cold dryer and suction dThe working principle of the refrigeration dryer::
The refrigerant is used for heat exchange with compressed air to reduce the compressed air temperature to the dew point temperature in the range of 2~10 °C. With the continuous development of the refrigeration dryer industry, more and more enterprises have entered the air compressor industry, more and more people are favored by the refrigeration dryer industry, and many enterprises stand out
The refrigeration dryer is divided into two types: air-cooled type and water-cooled type according to the cooling mode of the condenser;
According to the intake temperature, there are high-temperature intake type (below 80 °C) and normal temperature intake type (about 45 °C);
According to the working pressure, there are ordinary type (0.3-1.0MPa) and medium and high pressure type (above 1.2MPa).
In addition, many special specifications of refrigeration dryers can be used to process non-air media, such as: carbon dioxide, hydrogen, natural gas, blast furnace gas, nitrogen, etc
The main advantages of refrigeration dryers::
The chassis design adopts international industrial popular colors to meet various human needs;
Refrigeration and air systems, accurately calculated by experts, leave more than 20% of the actual price margin in the design parameters;
The inner and outer walls of the air heat exchanger are fully corrugated copper tubes, which fully comply with the law of conservation of energy, increase the utilization rate of cooling capacity, good temperature return, no frost, and low energy consumption;
The refrigerant heat exchanger adopts hydrophilic treatment thin-walled copper tube with pure aluminum heat exchanger, and the turbulence structure design has high heat exchange efficiency;
Shutter type separator and foam water separator integrate interception, collision and centrifugal effects, and the water separation efficiency is greater than 99%; Equipped with an electronic drain to reliably discharge condensate out of the machine to minimize air loss;
A variety of forms (single, set, PC board, frequency conversion, etc.) of the control line, suitable for different purposes of users; Electrical accessories adopt Siemens, Schneider and other well-known brands at home and abroad;
External rotor inlet cooling fan, large air volume, low noise, frequent start and stop and long life;
The refrigeration compressor adopts refrigeration compressors from well-known manufacturers at home and abroad, which has stable operation, low noise, reliable performance, power saving and long life;
The condenser adopts low-wing copper tube, slow water flow, multi-stroke, no water quality requirements, long-term use without scaling; High heat transfer coefficient, so small size and compact structure;
Overcurrent, overload, refrigerant high/low pressure display/protection, optional inlet and outlet water temperature, high and low air pressure and dew point protection:
The pressure-bearing parts are designed, manufactured, inspected, and randomly shipped according to the national standard GB151-99
